型号Model | XYT-EYE500-2.0 | |
测温范围Temperature range | 35.8℃~42℃ | |
测温距离和精度mperature measurement accuracy | 距离1.5~3m,测温精度:±0.2℃; | |
视角(宽*高)Angle of View (Width * Height) | FOV: 56°* 42°@可见光F6mm+红外F3.2mm( | |
图像采集Image Capture | 5~30帧可调 | |
编码类型 Coding type | H.264\H.265网络视频数字存储、传输 | |
供电方式Power supply mode | 适配器DC12V | |
功耗Power consumption | ≤5W | |
工作湿度Working humidity | ≤75% | |
重量(克)Weight (g) | 700 | |
尺寸(mm)Dimensions (mm) | 200*100*80 | |
环境温度Ambient temperature | 16℃~32℃ | |
校准黑体温度范围(可调) Calibration blackbody temperature range (adjustable) | 33℃~44℃ | |
基本功能Basic Functions | 自动环境温度补偿 Automatic ambient temperature compensation | 有 |
人体温度异常报警Alarm of abnormal temperature rise | 有 | |
监控端报警方式Alarm mode of monitoring end | 终端监控软件 | |
信息查询 Information Service | 故障、报警、数据黑匣子 | |
智能功能 Intelligent function | 人脸识别、温度异常目标自动捕捉 | |
